EQUIPMENT:
Linear Accelerator
Designed, optimized, and equipped to perform the most advanced treatments, Linear Accelerator is a sophisticated technology for modern radiation therapy departments.
Linear Accelerator is the device most commonly used for external beam radiation treatments for patients with cancer. The linear accelerator is used to treat all parts/organs of the body. It delivers high-energy x-rays to the region of the patient's tumor. These x-ray treatments can be designed in such a way that they destroy the cancer cells while sparing the surrounding normal tissue. The Linear Accelerator is used to treat all body sites, using conventional techniques, Intensity-Modulated Radiation Therapy (IMRT), Image Guided Radiation Therapy (IGRT), Stereotactic Radiosurgery (SRS) and Stereotactic Body Radio Therapy (SBRT).
The Linear Accelerator uses microwave technology to accelerate electrons in a part of the accelerator, and then allows these electrons to collide with a heavy metal target. As a result of the collisions, high-energy x-rays are produced from the target. These high energy x-rays are shaped as they exit the machine to conform to the shape of the patient's tumor and the customized beam is directed to the patient's tumor. The beam may be shaped either by blocks that are placed in the head of the machine or by a multi-leaf collimator that is incorporated into the head of the machine. The patient lies on a moveable treatment couch and lasers are used to make sure the patient is in the proper position. The treatment couch can move in many directions including up, down, right, left, in and out. The beam comes out of a part of the accelerator called a gantry, which can be rotated around the patient. Radiation can be delivered to the tumor from any angle by rotating the gantry and moving the treatment couch.
PET CT Scan:Positron emission tomography–computed tomography(PET-CT), is a medical imaging technique using a device which combines in a single gantry system both a positron emission tomography (PET) scanner and an x-ray computed tomography (CT) scanner, so that images acquired from both devices can be taken sequentially, in the same session, and combined into a single superposed (co-registered) image. Thus, functional imaging obtained by PET, which depicts the spatial distribution of metabolic or biochemical activity in the body can be more precisely aligned or correlated with anatomic imaging obtained by CT scanning. Two- and three-dimensional image reconstruction may be rendered as a function of a common software and control system.
PET-CT has revolutionized medical diagnosis in many fields, by adding precision of anatomic localization to functional imaging, which was previously lacking from pure PET imaging. For example, in oncology, surgical planning, radiation therapy and cancer staging have been changing rapidly under the influence of PET-CT availability, to the extent that many diagnostic imaging procedures and centers have been gradually abandoning conventional PET devices and substituting them by PET-CTs. Although the combined/hybrid device is considerably more expensive, it has the advantage of providing both functions as stand-alone examinations, being, in fact, two devices in one.
MRI
Magnetic resonance imaging (MRI) is a medical imaging technique used in radiology to investigate the anatomy and function of the body in both health and disease. MRI scanners use strong magnetic fields and radio waves to form images of the body structures. The technique is widely used in hospitals for medical diagnosis, staging of disease and for follow-up without exposure to ionizing radiation.
The MRI scanner is a tube surrounded by a giant circular magnet. The patient is placed on a moveable bed that is inserted into the magnet. The magnet creates a strong magnetic field that aligns the protons of hydrogen atoms, which are then exposed to a beam of radio waves. This spins the various protons of the body, and they produce a faint signal that is detected by the receiver portion of the MRI scanner. The receiver information is processed by a computer, and an image is produced.
The image and resolution produced by MRI is quite detailed and can detect tiny changes of structures within the body. For some procedures, contrast agents, such as gadolinium, are used to increase the accuracy of the images.
CT-Scan
Computed tomography (CT scan) is a technology that uses computer-processed x-rays to produce tomographic images of specific areas of the scanned object, it combines a series of X-ray views taken from many different angles and computer processing to create cross-sectional images of the bones and soft tissues inside your body.
The resulting images can be compared to looking down at single slices of bread from a loaf. Your doctor will be able to look at each of these slices individually or perform additional visualization to view your body from different angles. In some cases, CT images can be combined to create 3-D images. CT scan images can provide much more information than do plain X-rays.
A CT scan has many uses, but is particularly well suited to quickly examine people who may have internal injuries from car accidents or other types of trauma. A CT scan can be used to visualize nearly all parts of the body.
